MT201
Fully managed in-vehicle device for heavy vehicle fleets
Safely and effectively connect with your drivers in the field, replace manual processes with digitised workstreams and increase productivity.
Improve Safety
Streamline maintenance and driver coaching
Increase Productivity
Automate tasks and streamline job management
Digital Processes
Implement digital processes that improve the day-to-day operations of your business
Manage Compliance
Meet compliance requirements with digital tools
Key Features - Device & Software:
- Fatigue & electronic work diary
- Mass management
- Inspection checklists
- Customisable forms
- Electronic in-cab documents
- Speed management
- Real-time route guidance
- Job management
- Instant messaging
- Driver identification
- Fringe Benefits Tax
Key Features - Managed Service:
- Secured device
- Automatic updates
- Service desk access
- Device management
- Device provisioning
- Integration
- Device warranty
- Tracking and location
MT201
Technical Specifications
Certifications: CE/CB, FCC/IC, RCM, E-mark, ROHS, WEEE
Water/Dust Ingress: IP54
Shock and Vibration: SAE J1455 standard, up to 20G peaks
LTE: LTE/3G/2G
WiFi: 802.11 a/b/g/n/ac (2.4/5Ghz)
Bluetooth: BT 4.2+BLE
GNSS: GPS+AGPS, GLONASS, QZSS
CPU: Qualcomm SDM 450
Memory Storage: 4GB / 64GB, microsSD Expansion
Display: 7”, 600x 1024 pixels
Touchscreen: Anti-glare, Capacitative, Multi-point
Battery: 4,000mAh Li-ion Polymer, Battery life 8+ hours depending on usage
Operational Voltage: 9˜32V wide DC input
Current Consumption at 12V: Awake, idle ~250mA, Battery Charging ~1A
Cameras: Front: 8MP AF, Rear: 8MP AF with Flash
Microphone, Speaker: 2x Built-in microphones, 1x Built-in speaker
I/O Ports: 6-pin fleet port (Tx/Rx, 12/24V, IGN), Type C USB 2.0 port
Sensors: NFC sensor, Light sensor
Operating Temperature: -20°C to +60°C (-4° to +140°F) operating
Size: Height: 5.19", Width: 8.29", Depth: 0.8"
Weight: 16.9oz
Firmware Updates: Over-the-air (OTA)
Supported Platforms: DIRECTOR, TN360
